1. Product Overview
The NEV Electrical System Training Platform is an integrated diagnostic station designed to pair with the NEV Chassis System Training Platform. Utilizing MIL-STD aviation connectors, it provides direct access to low-voltage circuits for real-time measurement and analysis of critical EV subsystems, including:
• Battery Management System (BMS) & Charging Networks
• High-Voltage Distribution Unit (PDU)
• Climate Control & Thermal Management
• Body Electronics (Lighting, Wipers, Access Controls)
2. Core Technical Advantages
A. Precision Diagnostics
- Aviation-grade interfaces ensure signal integrity for measuring voltage/current waveforms, CAN bus traffic, and insulation resistance.
- Color-coded test points align with schematic diagrams for rapid fault isolation.
B. Industrial-Grade Construction
- 3mm reinforced aluminum composite panels with chemical-resistant silkscreen printing.
- Ergonomic steel frame (450mm work surface) with ESD-safe coating and dual-brake casters.
C. Smart Training Integration
- Compatible with OEM diagnostic tools for authentic workshop workflows.
- Supports open/short circuit injection for failure mode analysis.
3. Pedagogical Value Proposition
Scenario-Based Learning
- Emulates 12+ real-world failure cases in BMS communication, charging handshakes, and HVAC control logic.
Cross-Disciplinary Skill Development
- Bridges high-voltage safety protocols with low-voltage system diagnostics.
- Reinforces systems thinking through chassis-electrical correlation exercises.
Certification Alignment
- Meets IMI/EATA L2/L3 competency requirements for NEV maintenance technicians.
